Reaction force: 7 identical boxes are place next each other?

7 identical boxes are place next each other

  1. The floor is smooth

  2. Each box has a mass of 1 kg

  3. g=10

4 coefficient of friction is 0.1 (i don't know why is it given.)

5 The 7 boxes is pushed by a force of 89 N from the left side

Find the force between box 5 and box 6. ( counting from the left side)

Can you please explain how to do this, Thank you.

Note by Peter Bishop
3 years, 9 months ago

No vote yet
1 vote

  Easy Math Editor

MarkdownAppears as
*italics* or _italics_ italics
**bold** or __bold__ bold

- bulleted
- list

  • bulleted
  • list

1. numbered
2. list

  1. numbered
  2. list
Note: you must add a full line of space before and after lists for them to show up correctly
paragraph 1

paragraph 2

paragraph 1

paragraph 2

[example link](https://brilliant.org)example link
> This is a quote
This is a quote
    # I indented these lines
    # 4 spaces, and now they show
    # up as a code block.

    print "hello world"
# I indented these lines
# 4 spaces, and now they show
# up as a code block.

print "hello world"
MathAppears as
Remember to wrap math in \( ... \) or \[ ... \] to ensure proper formatting.
2 \times 3 \( 2 \times 3 \)
2^{34} \( 2^{34} \)
a_{i-1} \( a_{i-1} \)
\frac{2}{3} \( \frac{2}{3} \)
\sqrt{2} \( \sqrt{2} \)
\sum_{i=1}^3 \( \sum_{i=1}^3 \)
\sin \theta \( \sin \theta \)
\boxed{123} \( \boxed{123} \)

Comments

Sort by:

Top Newest

Well, if the floor is smooth, coefficient of kinetic friction cannot be 0.1... Assuming the floor isn't smooth, let us consider the entire system of seven boxes (plus adorable massless cats) and draw its free-body diagram. Let us also assume that the force is enough to set all the boxes into motion with a constant rightward acceleration \(a\), which we need to find.

Then, we have a total leftward frictional force of \(F_{k}=\mu_{k}mg = 0.1 \times 7 kg \times 10 ms^{-2}= 7 N\). We have a total rightward applied force of \(89 N\). Since the vertical forces are balanced (because the boxes + cats are not accelerating vertically), the net force on the system is \(89 N-7 N = 82 N\) rightwards. But since we know the mass of the system, we can solve for its acceleration \(a\) using Newton's Second Law: \(F_{net} = ma \Longrightarrow a = \dfrac{F_{net}}{m} = \dfrac{82 N}{7 kg} = \dfrac{82}{7} ms^{-2}\)

So now we know that each box is accelerating rightwards with an acceleration of \(\dfrac{82}{7} ms^{-2}\). Now, let us consider Boxes 6 and 7 collectively as our system. The forces on this system (horizontal, not vertical) are the leftward frictional force (\(F_{k}=\mu_{k}mg = 0.1 \times 2 kg \times 10 ms^{-2}= 2 N\)) and the rightward reaction force \(F_{5,6}\) between Box 5 and Box 6. It is in fact this reaction force that actually accelerates Boxes 6 and 7, not the applied force.

So we can use Newton's Second Law again for this system: \(F_{net} = F_{5,6} - F_{k} = ma \Longrightarrow F_{5,6} = 2 kg \times \dfrac{82}{7} ms^{-2} + 2 N = \boxed{25.43 N}\).

Assuming that the floor is smooth, the problem becomes much simpler, due to the lack of frictional forces. The answer in that case can be easily computed in the same way.

Raj Magesh - 3 years, 9 months ago
