# Meddling with Mechanics problems!

Greetings Mechanics Lovers!

Since many people are starting their preparations for entering into most prestigious institute of India,(IITs),lets start a Mechanics Marathon.This Marathon will be topic-oriented,i.e. we will try to post good questions of certain topics for first three weeks.This note will help us to improve our problem solving strategy.

Rules are simple as other contest/marathons.

•I'll post two problems.If anybody solves any one of the two problems,s/he should post next problem within 3 hours.

•There will be max 2 unsolved problems at a time.

•Make sure you know how to solve your own problem before posting it, in case no one else is able to solve it within 24 hours. Then, you must post the solution and you have the right to post a new problem.

•It is NOT compulsory to post original problems. But make sure it has not been posted on brilliant.Also please don't post HC Verma questions or DC Pandey questions.

•There should be only one question. No sub questions allowed.No parts. Only one answer should be there.

•The scope of the problems is Jee-Advance and NSEP.(mechanics only).

Topics for first three weeks:

• Vectors

• Kinematics

• Laws of motion

• Work Energy and Power

• Circular Motion

• Center of mass.

Post only the problem and it's solution here. Extremely relevant comments are allowed.You are allowed to discuss solutions and problems here.

Solution to Problem (Insert Problem no here)



And put your Problem in a new thread following the format :

Problem (Insert Problem no here)



Remember to reshare this note so it goes to everyone out there. And above all else, have fun!

Note by Harsh Shrivastava
10 months, 1 week ago

Sort by:

Problem 5

A chain of length L is placed on a smooth spherical surface of radius R with one of its ends fixed at the top of the sphere . What will be the acceleration of each element of the chain when its upper end is released

It is assumed that the length of chain is less than quarter of the sphere · 10 months, 1 week ago

Solution to problem 5 :

Take a small element dx making angle $$d\theta$$ with centre ( at an angle $$\theta$$ with horizontal.)

Check for the tangential forces acting on it you will find that only one force act on it tangentially and that is

$$dm g cos\theta$$ $$( dm = \frac{MRd\theta}{L}$$ ( where M is assumed as mass of chain which will cancel at end))

[

Edited : Sorry guys , I left one thing { Credit to Deeparaj Bhat }

There is one more tangential force , that is dT , but since tension is an internal force the integration of dT vanish .

]

This is the force on a single element , integrate it to get the total force and then divide it by mass to get acceleration , which you will get as

$$a = \frac{gR}{L} ( 1 - cos(\frac{L}{R}))$$

Calculations I left for you ! · 10 months, 1 week ago

@Harsh Shrivastava if you can remove the barrier of topics on posting questions , I will like post my next q that will be original! And will include a combination of topics. · 10 months, 1 week ago

Comment deleted 10 months ago

Actually my q include rotation , conservation of momentum and all basic chapters , but never mind I will post sth. Related to the topic itself · 10 months, 1 week ago

Comment deleted 10 months ago

Comment deleted 10 months ago

Comment deleted 10 months ago

I will like to see your solution too! · 10 months, 1 week ago

As in your solution, just add a $$dT$$ (the change in tension) to the tangential forces. Integrate the expression with the appropiate limits.

Now, note that tension is an internal force and hence, $$\int dT$$ over the chain length vanishes.

We end up with the same answer finally. ;)

I know this is a very small point, but just thought that it's worth mentioning. · 10 months, 1 week ago

Thanks! I always like to learn :) , just can you also explain me how inegation of dT vanished

And should I delete my solution and you will post yours? · 10 months, 1 week ago

Comment deleted 10 months ago

Let me update my solution , and you are free to post the next question as I was wrong in one part :( · 10 months, 1 week ago

Is the answer a = (gR/L)(1 - cos (L/R)) · 10 months, 1 week ago

Correct! . Post next question and solution · 10 months, 1 week ago

Comment deleted 10 months ago

Its Not right to say acceleration of the chain As a whole as every element will be having an acceleration of different direction but their magnitude will be the same that i am asking to calculate · 10 months, 1 week ago

Comment deleted 10 months ago

Nope of each small element of chain ! . please do some analysis you will realise · 10 months, 1 week ago

Problem 2:

5 equal masses hang as shown in the figure.Find acceleration of each body.Assume pulleys to be frictionless,light and string is inextensible. · 10 months, 1 week ago

Its an elementary problem on virtual work method

By Symmetry Of forces acceleration of left most and right most will be same and acceleration of middle 3 will be same.

Apply Virtual work method

Call acceleration of extremum's to be a1 and middle ones to be a2

You get

2Ta1 = 6Ta2

a1 = 3a2

Apply Newton's second for two blocks

mg-T =ma1

2T-mg = ma2

Rest is algebra which is left as an exercise for reader

On Solving a1 = 3g/7 and a2 = g/7 · 10 months, 1 week ago

@Prakhar Bindal Hello Prakhar. Could you please tell me where I could learn about this Virtual Work method, especially on how to apply it for JEE problems? I had never heard of it before and it seems quite interesting! Thanks in advance! · 9 months, 2 weeks ago

Hey hello @Ishan Dasgupta Samarendra . Long time no see . how are you?

About your question actually i was taught this by my teacher in Laws Of Motion in FIITJEE .

I Am giving you some links for learning.

https://www.youtube.com/watch?v=lsHXK8nlLBs&feature=youtu.be · 9 months, 2 weeks ago

Thank you very much for the links. I'll go through them right away! I'm fine, thanks! Just buried under a huge amount of work, and hence sadly I've got no spare time for Brilliant. What about you? However I do see most of the problems you post on Chemistry; I really like them. Aachchaa, which books do you study from for P, C and M? As in theory as well as practice problems.Lastly, which center are you at FIITJEE? I seem to recall seeing your name once somewhere... · 9 months, 2 weeks ago

@Prakhar Bindal @Ishaan Dasgupta Samarendra

How did you guyz managed your time in class 11?

How many hours did you studied?

Please guide me.Thanks! · 9 months, 2 weeks ago

I too am not the right person to ask. However one of the major mistakes I made in class 11 was that I never planned by which dates to finish which chapters. One should always have a countdown so that one knows exactly how far behind/ahead one is. For example, say you practise questions for Physics from sources A,B and C. Then you must have days scheduled by when you'll finish A, B and C respectively. That way you'll know whether you have been working the way you had to, or not. · 9 months, 2 weeks ago

I Think i am not the right person to be asked . you must contact the people who have given JEE This year

@Mayank Singh @Deeparaj Bhat @Abhineet Nayyar · 9 months, 2 weeks ago

Thanks! . I Am bad at chemistry :P.

You too know the amount of work fiitjee people give :P . so i am left with very less amount of time to complete other books but still i have some

Maths---> I refer Amit Mohan Agarwal's Skills in mathematics Series by Arihant

Physics----> I Have HC Verma for theory and DC Pandey for problems . i too have irodov but i hardly pick it up

Chemistry----> Physical - NCERT For Theory and RC Mukherjee for problems

Organic- Solomon's for theory and Himanshu Pandey for problems

Inorganic---> :P . i have JD Lee but i haven't opened it from last 6 months!

I Am from FIITJEE East Delhi centre (Laxmi Nagar) . Where are you from ? . where did you saw my name? · 9 months, 2 weeks ago

Oh, I too have many of the books you use! Anyway thanks very much for telling me ! I'm from the South Delhi Center. I must have seen your name in some AIITS result or somewhere else. i really can't remember. · 9 months, 2 weeks ago

Might be. ! · 9 months, 2 weeks ago

Fun fact: Himanshu Pandey sir is my chemistry teacher(for inorganic and organic). · 9 months, 2 weeks ago

Cool! . he must be a master in organic chemistry · 9 months, 2 weeks ago

Problem 1:

Two particles, 1 and 2, move with constant velocities v1 and v2. At the initial moment their radius vectors are equal to r1 and r2. How must these four vectors be interrelated for the particles to collide? · 10 months, 1 week ago

Let the particles collide at point $$P$$, whose position vector is $${ r }_{ 3 }$$. Let the time taken be $$t$$. By the vector laws of addition, we get

$${ r }_{ 3 }={ { r }_{ 1 } }+{ v }_{ 1 }t\\ { r }_{ 3 }={ r }_{ 2 }+{ v }_{ 2 }t$$

$$\therefore$$. $${r_1}- {r_2} = ({v_2} -{v_1})t$$

$$\large t$$= $$\large\frac{({r_1} - {r_2})}{({v_2}-{v_1})}$$
From the system of equations,we get $$\large \frac{({r_1} - {r_2})}{|({r_1}-{r_2})|} = \frac{({v_2} -{v_1})}{(|{v_2}-{v_1}|)}$$

By intuition, we can tell that the particles $$1$$ and $$2$$ collide when velocity of the second is directed towards the first. In that case, the velocity vectors turn parallel to the position vectors, thus making their unit vectors equal. · 10 months, 1 week ago

Nice solution (+1) :).

Don't you think the velocities, in addition of being parallel, must be not be equal to each other in case $$r_{1} ≠ r_{2}$$ ? · 10 months, 1 week ago

Comment deleted 10 months ago

Nah.Anyone can participate. · 10 months, 1 week ago

Thanks For The Invite.Is the answer to this question v2 vector-v1vector/mod(v2 vector -v1 vector)=r2vector-r1vector/mod(r2vector-r1 vector) · 10 months, 1 week ago

Problem 10

A meteorite of mass m collides with a satellite which was oribiting around a planet of mass $$M$$ in a circular orbit of radius R . Due to collision, the meteorite sticks to satellite and satellite is seen to have entered an orbit in which its minimum distance from the planet is $$\frac{R}{2}$$. If mass of the satellite is is 10 times that of the meteorite , What was the velocity of the meteorite before collision ? (edit : Assume velocity of meteorite was initially perpendicular to that of the satellite) · 2 months, 3 weeks ago

Its a simple energy , momentum and angular momentum conservation problem

on solving v turns out to be sqrt (58GM/R) · 2 months, 3 weeks ago

Post the next problem! · 2 months, 3 weeks ago

I might I have done a serious calculation mistake coz I also did the same. · 2 months, 3 weeks ago

Yes :P.......Plz post the next problem · 2 months, 3 weeks ago

Is the answer sqrt(288GM/R)? · 2 months, 3 weeks ago

no · 2 months, 3 weeks ago

Problem 8:

A cylinder of mass $$m$$ and radius $$R$$ rest on two supports in the same height .One support is stationery while the other slides from the cylinder at velocity $$v$$. Determine the force of normal pressure $$N$$ by cylinder at stationery support when $$x=R\sqrt{2}$$. · 10 months, 1 week ago

Solution to problem 8:

As the cylinder remains in contact with the stationary support it does circular motion about that point. As the cylinder is in contact with the block so the velocity of block on the normal of point of contact (which passes through center of cylinder) should be equal to that of cylinder.

$$\Rightarrow v_c = \dfrac{v}{\sqrt{2}}$$

As the block does circular motion the forces perpendicular to the point of contact provide the required centripetal force.

$$mg \cos {45^{\circ}} - N = \dfrac{mv_c ^2}{R}$$

$$N = \dfrac{mg}{\sqrt{2}} - \dfrac{mv^2}{2R}$$ · 10 months, 1 week ago

go and post the next q · 10 months, 1 week ago

How to post image. ? I need image to illustrate the question. · 10 months, 1 week ago

when will you post q · 10 months, 1 week ago

you just get the link by by copying it from publish place where you post q. · 10 months, 1 week ago

Solution to Problem 8:

The answer is $$n=\frac{mg}{\sqrt{2}}-\frac{mv^2}{2R}$$. Due to time constraint I can't post the complete solution. But it can be found out by balancing forces. The angle made with horizontal can be found out by basic geometry. The velocity of the cylinder is $$\frac{v}{\sqrt{2}}$$. This can be found out by equating components. · 10 months, 1 week ago

I can't find a good problem now, can anyone else post it? · 10 months, 1 week ago

Problem 4:

The trajectory for motion of a particle in $$x-y$$ plane can be expressed as given below,

$e^x+e^y=e^x e^y, x,y \in \mathbb{R}$

It is given that acceleration of this particle is zero and its initial velocity in $$x$$ and $$y$$ direction are $$1 \text{m/s}$$ and $$2 \text{m/s}$$ respectively. Also if its initial coordinates can be expressed in form integers, then find the initial coordinates $$(x,y)$$ of the particale.

P. S. : Original problem. · 10 months, 1 week ago

Given equation:

$1=e^{-x}+e^{-y} \\\implies 0=e^{-x}+2e^{-y} \\ (\text{differentiating wrt time } \frac{dx}{dt}=1\: \frac{dy}{dt}=2) \\\implies -1=e^{-y} \\\text{No real solution}\\\large Q. E. D.$ · 10 months, 1 week ago

Can you please explain third line of you solution ? · 10 months, 1 week ago

I meant that the second line is obtained after differentiating the given equation and using the given facts. · 10 months, 1 week ago

Correct! post the next question! · 10 months, 1 week ago

Comment deleted 10 months ago

If that is what you wish, then I will post the next question. Did you liked this problem? · 10 months, 1 week ago

Post the next problem. · 10 months, 1 week ago

It was quite different from the usual ones. And I like such problems ;) · 10 months, 1 week ago

Comment deleted 10 months ago

Yeah! Write the solution to it too. · 10 months, 1 week ago

Problem 3: The velocity of a particle moving in the positive direction of the $$x$$ axis varies as $$v=\alpha\sqrt{x}$$, where $$\alpha$$ is a positive constant. Assuming that at the moment $$t=0$$ the particle was located at the point $$x=0$$, find the time dependence of the velocity and acceleration of the particle. · 10 months, 1 week ago

$$v=\alpha^2t/2$$ and $$a=\alpha^2/2$$.

We know,

$$v=\frac{dx}{dt}=\alpha x^{1/2}$$

$$x^{-1/2}dx=\alpha dt$$

$$\displaystyle \int_{0}^{x}x^{-1/2}dx=\displaystyle \int_{0}^{t} \alpha dt$$

$$2x^{1/2}=\alpha t$$

$$x=\alpha^2 t^2/4$$

By differentiation,

$$v=\alpha^2 t/2$$

$$a=\alpha^2/2$$ · 10 months, 1 week ago

Correct.You perhaps can post the next question. · 10 months, 1 week ago

PROBLEM 11

Moment of inertia of a uniform hexagonal plate about an axis LL' is I . The moment of inertia (about XX') of an equilateral uniform triangular plate of thickness double that of hexagonal plate is P . (specific gravity of triangular plate is 3 times that of hexagonal plate)

Find I/P · 2 months, 3 weeks ago

https://s28.postimg.org/vhjxmwknx/Untitled.png · 2 months, 3 weeks ago

http://tinypic.com/view.php?pic=2ludvn5&s=9#.WGoB81N96M8 · 2 months, 3 weeks ago

ans is 5 · 2 months, 3 weeks ago

Post the next problem , a tough one! · 2 months, 3 weeks ago

This was very similar to a problem which appeared in our AITS 1 · 2 months, 3 weeks ago

wasn't this one tough? :P · 2 months, 3 weeks ago

It was tough indeed, though I have only tried it once. · 2 months, 3 weeks ago

Yup correct! · 2 months, 3 weeks ago

Is this dead? Shall I participate · 2 months, 3 weeks ago

If you want you may post problems here and I will participate here.So post the next problem ! · 2 months, 3 weeks ago

Can u derive the equation of trajectory of each particle in the Irodov question no 1.12? · 2 months, 3 weeks ago

Is the contest dead? · 9 months, 4 weeks ago

Oh, sad. But no worries! I'll be coming up with an Electromagnetism contest on Monday, be sure to take part! · 9 months, 3 weeks ago

Yeah :P . No more activity as we all are quite busy with our class 12th! · 9 months, 4 weeks ago

Problem 9

A metal rod is of length $$1m$$ is clamped at points $$5cm$$ and $$15 cm$$ from either ends. Find the minimum frequency of natural longitudinal oscillations of rod.

Given :

• Young's modulus of rod $$= 1.6 \times 10^{11} Pa$$

• Mass per unit volume $$\rho = 2500 kgm^{-3}$$

· 10 months, 1 week ago

I did it like this. The particles at ends of the rod are the ones which will oscillate with max amplitude(antinodes). In case of minimum frequency , we are looking to maximize wavelength. Hence consider the case when antinode is at one end and first node is at the hinge 5cm from it.(This also takes care of a node being at the other point that is hinged) . hence max wavelength is 20cm. Thus min frequency is $$40,000 Hz$$ · 2 months, 3 weeks ago

Awesome! We got a new problem poster!

Post the next problem please! · 2 months, 3 weeks ago

correct! · 2 months, 3 weeks ago

Comment deleted 2 months ago

no · 2 months, 3 weeks ago

pic · 10 months, 1 week ago

Rod is clamped at a distance 5cm from one end and 15 cm from other end. Its easily understandable i guess. · 10 months, 1 week ago

yep it is but i thought you were not able to do as guided by me. · 10 months, 1 week ago

yes i didn't understand the method u said to post the pic. · 10 months, 1 week ago

be on slack · 10 months, 1 week ago

I need to go to coaching right now. so talk to you later · 10 months, 1 week ago

ok bye today i have coaching too from 2-30 so better talk at 9-00 · 10 months, 1 week ago

Problem 7: A lift of total mass M kg is raised by cables from rest to rest through a height h.The greatest tension which the cables can safely bear is n Mg Newtons(n>1).Find the shortest interval of time in which the ascent can be made,in terms of n,h,g. · 10 months, 1 week ago

now this can have multiple ans depending on if cables are also attached at bottom for retardation or not i assume that the cable bring only acceleration and retardation is brought up by g only in that case i hope t(min)=root(2h/{n(n-1)g})(considering at a ht h v=0) · 10 months, 1 week ago

The latter case is correct!Well done!Post the next question please! · 10 months, 1 week ago

Hey guyz,please delete unnecessary comments as the note is getting slow.Thanks. · 10 months, 1 week ago

Problem 6 : [Original]

Take a bomb of mass m and give it a velocity $$v = 10m/sec$$ at an angle $$\theta = 53°$$with horizontal. The bomb bursts into two identical parts when it's velocity made an angle +45° with horizontal. Just after the breakdown, One of the part's velocity was found to be $$6 m/sec$$ in horizontal direction. (i. e. It retained it's horizontal component of velocity ) . Find the final displacement of one part with respect to other after they come to rest.

Details And Assumptions :

• The coefficient of restitution for the ball ground collision is $$e = 0.4$$

• The ground is smooth.

• Take $$g = 10m/s^2$$

· 10 months, 1 week ago

· 10 months, 1 week ago

this gives ans as 16.71 as suggested by @Aniket Sanghi i request to find a mistake in this. · 10 months, 1 week ago

· 10 months, 1 week ago

this gives ans 18.1527 as mentioned by @Adarsh Kumar i would request to find a mistake in this????? · 10 months, 1 week ago

Thanx!@aryan goyat for posting this! · 10 months, 1 week ago

Go! Post the next question for now @AdarshKumar · 10 months, 1 week ago

Ohk,gimme a minute I just woke up :P. · 10 months, 1 week ago

welcome · 10 months, 1 week ago

You may post the solution and the next problem.

@Aniket Sanghi · 10 months, 1 week ago

Comment deleted 10 months ago

Got at same 14.78379 m .

@aryan goyat @Aniket Sanghi · 10 months, 1 week ago

be on slack · 10 months, 1 week ago

Nope , my answer is different · 10 months, 1 week ago

bro come on slack · 10 months, 1 week ago

Comment deleted 10 months ago

ya and only one correct ans 'bohot nainsafe hai' · 10 months, 1 week ago

Comment deleted 10 months ago

ok will be there now · 10 months, 1 week ago

Comment deleted 10 months ago

Nope · 10 months, 1 week ago

Can you figure out mistake in process?- What i did was conserving momentum along x and y axis. Both masses had 6m/s velocity in x direction , one having 12m/s up. Using these, i solved for time( using GP sum) and then difference of distance. · 10 months, 1 week ago

I am getting 18.15. · 10 months, 1 week ago

did you solve in same way as i did? · 10 months, 1 week ago

I got the same numbers as you, but after that I used difference of ranges by using infinite gp. · 10 months, 1 week ago

Yes the same way · 10 months, 1 week ago

Ohk,so you first found out difference in ranges after 1st collision with the ground and then added it to difference in range before 1st collision? · 10 months, 1 week ago

Indirectly the same. Instead i solved for the time before and after the first collision, then multiplying 6(horizontal speed), differenced them. · 10 months, 1 week ago

Yup!That is almost the same way,I think :P ! · 10 months, 1 week ago

@Prakhar Bindal we really need your help! · 10 months, 1 week ago

· 10 months, 1 week ago

this gives ans as 14.782 as suggested by @Prakhar Bindal i request to find a mistake in it?? · 10 months, 1 week ago

@Aniket Sanghi @Deeparaj Bhat please post the next question! · 10 months, 1 week ago

I am inviting few people to join the contest, sorry for mass taging.

@Akshay Yadav @Aniket Sanghi @Adarsh Kumar @Chinmay Sangawadekar @Vaibhav Prasad @Kalash Verma @Hrishik Mukherjee. @Nihar Mahajan @Prakhar Bindal @Swapnil Das @Rajdeep Dhingra @Shreya R @milind prabhu @Kaustubh Miglani @Vighnesh shenoy · 10 months, 1 week ago

Thanks for inviting :) · 10 months, 1 week ago
